NR-NE48 Series
POWER (WATT)
5.0/9.0
IP RATING
IP65
CCT
3000K/4000K
BEAM ANGLE
120°
Ra
97
Technical Specifications Basic Parameters
Model No
NR-NE48 Series
Category
LED Neon Strip Light
Installation Methods
Surface Mounted
Classes of Electrical Protection
Class III
IP Rating
IP65
ta
50°C
Input Voltage
DC48V
Frequency
Type of Chips
SMD
Watt
5.0/9.0
lm/w
50.0
Useful Lumen
250.0/450.0
CCT
3000K/4000K
Beam Angle
120°
Ra
97
PF
1.0
DF
1.0
Body Color
White
Product Main Material
Dimming or not
Non-Adjustable Light
Cut hole (mm)
Guarantee
3
Directionality
Indirect
Product Size (mm)
50000*17*12/50000*13*12
Energy efficiency QR included
Model Variants 4 beam options
| Item Code | New Model No | Category | Installation Methods | Classes of Electrical Protection | IP Rating | ta | Input Voltage | Frequency | Type of Chips | Watt | lm/w | Useful Lumen | CCT | Beam Angle | Ra | PF | DF | Body Color | Product Main Material | Dimming or not | Cut hole (mm) | Guarantee | Directionality | Product Size (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NR-NE48-1217-5W-3000K | NR-O4SS0101-5-30K | LED Neon Strip Light | Surface Mounted | Class III | IP65 | 50°C | DC48V | N/A | SMD | 5.0 | 50.0 | 250.0 | 3000K | 120° | 97 | 1.0 | 1.0 | White | Non-Adjustable Light | N/A | 3 | Indirect | 50000*17*12 | |
| NR-NE48-1217-5W-4000K | NR-O4SS0101-5-40K | LED Neon Strip Light | Surface Mounted | Class III | IP65 | 50°C | DC48V | N/A | SMD | 5.0 | 50.0 | 250.0 | 4000K | 120° | 97 | 1.0 | 1.0 | White | Non-Adjustable Light | N/A | 3 | Indirect | 50000*17*12 | |
| NR-NE48-1217-9W-3000K | NR-O4SS0101-9-30K | LED Neon Strip Light | Surface Mounted | Class III | IP65 | 50°C | DC48V | N/A | SMD | 9.0 | 50.0 | 450.0 | 3000K | 120° | 97 | 1.0 | 1.0 | White | Non-Adjustable Light | N/A | 3 | Indirect | 50000*17*12 | |
| NR-NE48-1217-9W-4000K | NR-O4SS0101-9-40K | LED Neon Strip Light | Surface Mounted | Class III | IP65 | 50°C | DC48V | N/A | SMD | 9.0 | 50.0 | 450.0 | 4000K | 120° | 97 | 1.0 | 1.0 | White | Non-Adjustable Light | N/A | 3 | Indirect | 50000*17*12 | |
| NR-NE48-1312-5W-3000K | NR-O4SS0102-5-30K | LED Neon Strip Light | Surface Mounted | Class III | IP65 | 50°C | DC48V | N/A | SMD | 5.0 | 50.0 | 250.0 | 3000K | 120° | 97 | 1.0 | 1.0 | White | Non-Adjustable Light | N/A | 3 | Indirect | 50000*13*12 | |
| NR-NE48-1312-5W-4000K | NR-O4SS0102-5-40K | LED Neon Strip Light | Surface Mounted | Class III | IP65 | 50°C | DC48V | N/A | SMD | 5.0 | 50.0 | 250.0 | 4000K | 120° | 97 | 1.0 | 1.0 | White | Non-Adjustable Light | N/A | 3 | Indirect | 50000*13*12 | |
| NR-NE48-1312-9W-3000K | NR-O4SS0102-9-30K | LED Neon Strip Light | Surface Mounted | Class III | IP65 | 50°C | DC48V | N/A | SMD | 9.0 | 50.0 | 450.0 | 3000K | 120° | 97 | 1.0 | 1.0 | White | Non-Adjustable Light | N/A | 3 | Indirect | 50000*13*12 | |
| NR-NE48-1312-9W-4000K | NR-O4SS0102-9-40K | LED Neon Strip Light | Surface Mounted | Class III | IP65 | 50°C | DC48V | N/A | SMD | 9.0 | 50.0 | 450.0 | 4000K | 120° | 97 | 1.0 | 1.0 | White | Non-Adjustable Light | N/A | 3 | Indirect | 50000*13*12 |
