NR-NE24 Series
POWER (WATT)
8.0/9.0/10.0
IP RATING
IP65
CCT
3000K/4000K
BEAM ANGLE
120°
Ra
80/90
Technical Specifications Basic Parameters
Model No
NR-NE24 Series
Category
LED Neon Strip Light
Installation Methods
Surface Mounted
Classes of Electrical Protection
Class III
IP Rating
IP65
ta
50°C
Input Voltage
DC24V
Frequency
Type of Chips
SMD
Watt
8.0/9.0/10.0
lm/w
25.0/66.0/40.0
Useful Lumen
200.0/594.0/400.0
CCT
3000K/4000K
Beam Angle
120°
Ra
80/90
PF
1.0
DF
1.0
Body Color
White
Product Main Material
Dimming or not
Non-Adjustable Light
Cut hole (mm)
10*10
Guarantee
3
Directionality
Indirect
Product Size (mm)
5000*6*12/5000*14*10/5000*11*6
Energy efficiency QR included
Model Variants 4 beam options
| Item Code | New Model No | Category | Installation Methods | Classes of Electrical Protection | IP Rating | ta | Input Voltage | Frequency | Type of Chips | Watt | lm/w | Useful Lumen | CCT | Beam Angle | Ra | PF | DF | Body Color | Product Main Material | Dimming or not | Cut hole (mm) | Guarantee | Directionality | Product Size (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NR-NE24-0612-8W-3000K | NR-ST24-8 SWW | LED Neon Strip Light | Surface Mounted | Class III | IP65 | 50°C | DC24V | N/A | SMD | 8.0 | 25.0 | 200.0 | 3000K | 120° | 80 | 1.0 | 1.0 | White | Non-Adjustable Light | N/A | 3 | Indirect | 5000*6*12 | |
| NR-NE24-0612-8W-4000K | NR-ST24-8 DW | LED Neon Strip Light | Surface Mounted | Class III | IP65 | 50°C | DC24V | N/A | SMD | 8.0 | 25.0 | 200.0 | 4000K | 120° | 80 | 1.0 | 1.0 | White | Non-Adjustable Light | N/A | 3 | Indirect | 5000*6*12 | |
| NR-NE24-1010-9W-3000K | NR-NE24C-120-9 WW | LED Neon Strip Light | Surface Mounted | Class III | IP65 | 50°C | DC24V | N/A | SMD | 9.0 | 66.0 | 594.0 | 3000K | 120° | 80 | 1.0 | 1.0 | White | Non-Adjustable Light | 10*10 | 3 | Indirect | 5000*14*10 | |
| NR-NE24-1010-9W-4000K | NR-NE24C-120-9 DW | LED Neon Strip Light | Surface Mounted | Class III | IP65 | 50°C | DC24V | N/A | SMD | 9.0 | 66.0 | 594.0 | 4000K | 120° | 80 | 1.0 | 1.0 | White | Non-Adjustable Light | 10*10 | 3 | Indirect | 5000*14*10 | |
| NR-NE24COB-1106-10W-3000K | NR-NE24A-36-10 SWW | LED Neon Strip Light | Surface Mounted | Class III | IP65 | 50°C | DC24V | N/A | SMD | 10.0 | 40.0 | 400.0 | 3000K | 120° | 90 | 1.0 | 1.0 | White | Non-Adjustable Light | N/A | 3 | Indirect | 5000*11*6 | |
| NR-NE24COB-1106-10W-4000K | NR-NE24A-36-10 SDW | LED Neon Strip Light | Surface Mounted | Class III | IP65 | 50°C | DC24V | N/A | SMD | 10.0 | 40.0 | 400.0 | 4000K | 120° | 90 | 1.0 | 1.0 | White | Non-Adjustable Light | N/A | 3 | Indirect | 5000*11*6 |
