NR-ST24-COB
POWER (WATT)
9.0/10.0
IP RATING
IP20
CCT
3000K/4000K
BEAM ANGLE
120°
Ra
90
Technical Specifications Basic Parameters
Model No
NR-ST24-COB Series
Category
LED Strip Light
Installation Methods
Surface Mounted
Classes of Electrical Protection
Class III
IP Rating
IP20
ta
40°C
Input Voltage
DC24V
Frequency
Type of Chips
COB
Watt
9.0/10.0
lm/w
66.0/100.0
Useful Lumen
594.0/1000.0
CCT
3000K/4000K
Beam Angle
120°
Ra
90
PF
1.0
DF
1.0
Body Color
Product Main Material
Dimming or not
Non-Adjustable Light
Cut hole (mm)
Guarantee
3/5
Directionality
Indirect
Product Size (mm)
5000*8*2/5000*8*3
Energy efficiency QR included
Model Variants 4 beam options
| Item Code | New Model No | Category | Installation Methods | Classes of Electrical Protection | IP Rating | ta | Input Voltage | Frequency | Type of Chips | Watt | lm/w | Useful Lumen | CCT | Beam Angle | Ra | PF | DF | Body Color | Product Main Material | Dimming or not | Cut hole (mm) | Guarantee | Directionality | Product Size (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NR-ST24-COB-9W-3000K | NR-ST24D-280-9 WW | LED Strip Light | Surface Mounted | Class III | IP20 | 40°C | DC24V | N/A | COB | 9.0 | 66.0 | 594.0 | 3000K | 120° | 90 | 1.0 | 1.0 | Non-Adjustable Light | N/A | 3 | Indirect | 5000*8*2 | ||
| NR-ST24-COB-9W-4000K | NR-ST24D-280-9 DW | LED Strip Light | Surface Mounted | Class III | IP20 | 40°C | DC24V | N/A | COB | 9.0 | 66.0 | 594.0 | 4000K | 120° | 90 | 1.0 | 1.0 | Non-Adjustable Light | N/A | 3 | Indirect | 5000*8*2 | ||
| NRP-ST24-COB-10W-3000K | NRP-ST24D-280-10 WW | LED Strip Light | Surface Mounted | Class III | IP20 | 40°C | DC24V | N/A | COB | 10.0 | 100.0 | 1000.0 | 3000K | 120° | 90 | 1.0 | 1.0 | Non-Adjustable Light | N/A | 5 | Indirect | 5000*8*3 | ||
| NRP-ST24-COB-10W-4000K | NRP-ST24D-280-10 DW | LED Strip Light | Surface Mounted | Class III | IP20 | 40°C | DC24V | N/A | COB | 10.0 | 100.0 | 1000.0 | 4000K | 120° | 90 | 1.0 | 1.0 | Non-Adjustable Light | N/A | 5 | Indirect | 5000*8*3 |
