NR-TL Series
POWER (WATT)
10.0/20.0/30.0/12.0/7.0/60.0/24.0
IP RATING
IP20
CCT
3000K/6500K/4000K/15-50/1800K/2400K
BEAM ANGLE
24°/90°
Ra
80/90/95
Technical Specifications Basic Parameters
Model No
NR-TL Series
Category
LED Track Light
Installation Methods
Portable
Classes of Electrical Protection
Class II/Class I
IP Rating
IP20
ta
40°C
Input Voltage
AC220-240V
Frequency
Hz
Type of Chips
COB/SMD
Watt
10.0/20.0/30.0/12.0/7.0/60.0/24.0
lm/w
85.0/80.0/90.0/100.0/110.0/74.0/71.0/150.0/140.0/50.0
Useful Lumen
0/850.0/1600.0/1700.0/2700.0/3000.0/3300.0/2220.0/710.0/2400.0/1480.0/9000.0/3360.0/1500.0
CCT
3000K/6500K/4000K/15-50/1800K/2400K
Beam Angle
24°/90°
Ra
80/90/95
PF
0.5/0.9
DF
0.7/0.9
Body Color
Black/White
Product Main Material
Aluminum/Aluminum + PC
Dimming or not
Non-Adjustable Light
Cut hole (mm)
Guarantee
3/5
Directionality
Direct
Product Size (mm)
124*63*187/146*85*202/177*95*230/162*23*153/303*23*153/447*23*153/158*55*200/158*65*210/158*80*236/234*80*255/1493*62*42/600*62*42/200*80*223
Energy efficiency QR included
Model Variants 4 beam options
| Item Code | New Model No | Category | Installation Methods | Classes of Electrical Protection | IP Rating | ta | Input Voltage | Frequency | Type of Chips | Watt | lm/w | Useful Lumen | CCT | Beam Angle | Ra | PF | DF | Body Color | Product Main Material | Dimming or not | Cut hole (mm) | Guarantee | Directionality | Product Size (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NR-TL-CLB60-10-3000K-BK | NR-TL0201-10-30K-BK-15D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | 10.0 | 0 | ||||||||||||||
| NR-TL-CLB60-10-3000K-WH | NR-TL0201-10-30K-WH-15D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | 10.0 | 0 | ||||||||||||||
| NR-TL101COB-10-BK-3000K | NR-TL0151-10-30K-BK-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 10.0 | 85.0 | 850.0 | 3000K | 24° | 80 | 0.5 | 0.7 | Black | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | 124*63*187 |
| NR-TL101COB-10-BK-6500K | NR-TL0151-10-65K-BK-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 10.0 | 85.0 | 850.0 | 6500K | 24° | 80 | 0.5 | 0.7 | Black | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | 124*63*187 |
| NR-TL101COB-10-W-3000K | NR-TL0151-10-30K-WH-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 10.0 | 85.0 | 850.0 | 3000K | 24° | 80 | 0.5 | 0.7 | White | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | 124*63*187 |
| NR-TL101COB-10-W-6500K | NR-TL0151-10-65K-WH-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 10.0 | 85.0 | 850.0 | 6500K | 24° | 80 | 0.5 | 0.7 | White | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | 124*63*187 |
| NR-TL101COB-20-BK-3000K | NR-TL0151-20-30K-BK-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 20.0 | 80.0 | 1600.0 | 3000K | 24° | 80 | 0.5 | 0.9 | Black | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | 146*85*202 |
| NR-TL101COB-20-BK-4000K | NR-TL0151-20-40K-BK-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 20.0 | 80.0 | 1600.0 | 4000K | 24° | 80 | 0.5 | 0.9 | Black | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | 146*85*202 |
| NR-TL101COB-20-BK-6500K | NR-TL0151-20-65K-BK-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 20.0 | 85.0 | 1700.0 | 3000K | 24° | 80 | 0.5 | 0.9 | Black | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | 146*85*202 |
| NR-TL101COB-20-W-3000K | NR-TL0151-20-30K-WH-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 20.0 | 80.0 | 1600.0 | 3000K | 24° | 80 | 0.5 | 0.9 | White | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | 146*85*202 |
| NR-TL101COB-20-W-4000K | NR-TL0151-20-40K-WH-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 20.0 | 80.0 | 1600.0 | 4000K | 24° | 80 | 0.9 | 0.9 | White | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | 146*85*202 |
| NR-TL101COB-20-W-6500K | NR-TL0151-20-65K-WH-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 20.0 | 80.0 | 1600.0 | 6500K | 24° | 80 | 0.9 | 0.9 | White | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | 146*85*202 |
| NR-TL101COB-30-BK-3000K | NR-TL0151-30-30K-BK-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 30.0 | 90.0 | 2700.0 | 3000K | 24° | 80 | 0.9 | 0.9 | Black | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | 177*95*230 |
| NR-TL101COB-30-BK-4000K | NR-TL0151-30-40K-BK-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 30.0 | 100.0 | 3000.0 | 4000K | 24° | 80 | 0.9 | 0.9 | Black | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | 177*95*230 |
| NR-TL101COB-30-BK-6500K | NR-TL0151-30-65K-BK-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 30.0 | 110.0 | 3300.0 | 6500K | 24° | 80 | 0.9 | 0.9 | Black | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | 177*95*230 |
| NR-TL101COB-30-W-3000K | NR-TL0151-30-30K-WH-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 30.0 | 90.0 | 2700.0 | 3000K | 24° | 80 | 0.9 | 0.9 | White | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | 177*95*230 |
| NR-TL101COB-30-W-4000K | NR-TL0151-30-40K-WH-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 30.0 | 110.0 | 3300.0 | 4000K | 24° | 80 | 0.9 | 0.9 | White | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | 177*95*230 |
| NR-TL101COB-30-W-6500K | NR-TL0151-30-65K-WH-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 30.0 | 110.0 | 3300.0 | 6500K | 24° | 80 | 0.9 | 0.9 | White | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | 177*95*230 |
| NR-TL103-10-3000K-BK | NR-TL0101-10-30K-BK-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | SMD | 10.0 | 85.0 | 850.0 | 3000K | 24° | 90 | 0.5 | 0.7 | Black | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | 162*23*153 |
| NR-TL103-10-3000K-WH | NR-TL0101-10-30K-WH-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | SMD | 10.0 | 0 | |||||||||||||
| NR-TL103-12W-3000K-BK | NR-TL103-12 WW | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | SMD | 12.0 | 0 | |||||||||||||
| NR-TL103-12W-3000K-WH | NR-TL0101-12-30K-WH-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | SMD | 12.0 | 0 | |||||||||||||
| NR-TL103-12W-4000K-BK | NR-TL103-12 DW | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | SMD | 12.0 | 0 | |||||||||||||
| NR-TL103-12W-4000K-WH | NR-TL0101-12-40K-WH-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | SMD | 12.0 | 0 | |||||||||||||
| NR-TL103-20-3000K-BK | NR-TL0101-20-30K-BK-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | SMD | 20.0 | 80.0 | 1600.0 | 3000K | 24° | 90 | 0.5 | 0.7 | Black | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | 303*23*153 |
| NR-TL103-20-3000K-WH | NR-TL0101-20-30K-WH-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | SMD | 20.0 | 0 | |||||||||||||
| NR-TL103-30-3000K-BK | NR-TL0101-30-30K-BK-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | SMD | 30.0 | 74.0 | 2220.0 | 3000K | 24° | 90 | 0.9 | 0.9 | Black | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | 447*23*153 |
| NR-TL103-30-3000K-WH | NR-TL0101-30-30K-WH-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | SMD | 30.0 | 0 | |||||||||||||
| NR-TL103-7W-3000K-BK | NR-TL0101-7-30K-BK-36D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | SMD | 7.0 | 0 | |||||||||||||
| NR-TL103-7W-3000K-WH | NR-TL0101-7-30K-WH-36D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | SMD | 7.0 | 0 | |||||||||||||
| NR-TL103-7W-4000K-BK | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | SMD | 7.0 | 0 | ||||||||||||||
| NR-TL103-7W-4000K-WH | NR-TL0101-7-40K-WH-36D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | SMD | 7.0 | 0 | |||||||||||||
| NR-TL104-10W-3000K | NR-TL104-10 WW | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | 10.0 | 0 | 15-50 | |||||||||||||
| NRP-TL102COB-10-BK-3000K | NRP-TL0151-10-30K-BK-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 10.0 | 71.0 | 710.0 | 3000K | 24° | 95 | 0.5 | 0.7 | Black | Aluminum | Non-Adjustable Light | N/A | 5 | Direct | 124*63*187 |
| NRP-TL102COB-10-BK-4000K | NRP-TL0151-10-40K-BK-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 10.0 | 71.0 | 710.0 | 4000K | 24° | 95 | 0.5 | 0.7 | Black | Aluminum | Non-Adjustable Light | N/A | 5 | Direct | 124*63*187 |
| NRP-TL102COB-10-W-3000K | NRP-TL0151-10-30K-WH-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 10.0 | 71.0 | 710.0 | 3000K | 24° | 95 | 0.5 | 0.7 | White | Aluminum | Non-Adjustable Light | N/A | 5 | Direct | 124*63*187 |
| NRP-TL102COB-10-W-4000K | NRP-TL0151-10-40K-WH-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 10.0 | 71.0 | 710.0 | 4000K | 24° | 95 | 0.5 | 0.7 | White | Aluminum | Non-Adjustable Light | N/A | 5 | Direct | 124*63*187 |
| NRP-TL102COB-20-BK-3000K | NRP-TL0151-20-30K-BK-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 20.0 | 80.0 | 1600.0 | 3000K | 24° | 95 | 0.5 | 0.7 | Black | Aluminum | Non-Adjustable Light | 5 | Direct | 146*85*202 | |
| NRP-TL102COB-20-BK-4000K | NRP-TL0152-20-40K-BK-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 20.0 | 80.0 | 1600.0 | 4000K | 24° | 95 | 0.5 | 0.7 | Black | Aluminum | Non-Adjustable Light | N/A | 5 | Direct | 146*85*202 |
| NRP-TL102COB-20-W-3000K | NRP-TL0151-20-30K-WH-24D | LED Track Light | Portable | Class II | IP20 | AC220-240V | Hz | 20.0 | 0 | |||||||||||||||
| NRP-TL102COB-20-W-4000K | NRP-TL0151-20-40K-WH-24D | LED Track Light | Portable | Class II | IP20 | AC220-240V | Hz | 20.0 | 0 | |||||||||||||||
| NRP-TL102COB-30-BK-3000K | NRP-TL0151-30-30K-BK-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 30.0 | 74.0 | 2220.0 | 3000K | 24° | 95 | 0.9 | 0.9 | Black | Aluminum | Non-Adjustable Light | N/A | 5 | Direct | 177*95*230 |
| NRP-TL102COB-30-BK-4000K | NRP-TL0151-30-40K-BK-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 30.0 | 74.0 | 2220.0 | 4000K | 24° | 95 | 0.9 | 0.9 | Black | Aluminum | Non-Adjustable Light | N/A | 5 | Direct | 177*95*230 |
| NRP-TL102COB-30-W-3000K | NRP-TL0151-30-30K-WH-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 30.0 | 74.0 | 2220.0 | 3000K | 24° | 95 | 0.9 | 0.9 | White | Aluminum | Non-Adjustable Light | N/A | 5 | Direct | 177*95*230 |
| NRP-TL102COB-30-W-4000K | NRP-TL0151-30-40K-WH-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 30.0 | 80.0 | 2400.0 | 4000K | 24° | 95 | 0.9 | 0.9 | White | Aluminum | Non-Adjustable Light | N/A | 5 | Direct | 177*95*230 |
| NR-TL0153-10-30K-WH-24D | NR-TL0153-10-30K-WH-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 10.0 | 71.0 | 710.0 | 3000K | 24° | 90 | 0.5 | 0.7 | White | Aluminum + PC | Non-Adjustable Light | N/A | 5 | Direct | 158*55*200 |
| NR-TL0153-10-30K-BK-24D | NR-TL0153-10-30K-BK-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 10.0 | 71.0 | 710.0 | 3000K | 24° | 90 | 0.5 | 0.7 | Black | Aluminum + PC | Non-Adjustable Light | N/A | 5 | Direct | 158*55*200 |
| NR-TL0153-20-30K-BK-24D | NR-TL0153-20-30K-BK-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 20.0 | 74.0 | 1480.0 | 3000K | 24° | 90 | 0.5 | 0.7 | Black | Aluminum + PC | Non-Adjustable Light | N/A | 5 | Direct | 158*65*210 |
| NR-TL0153-30-40K-WH-24D | NR-TL0153-30-40K-WH-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 30.0 | 74.0 | 2220.0 | 4000K | 24° | 90 | 0.9 | 0.9 | White | Aluminum + PC | Non-Adjustable Light | N/A | 5 | Direct | 158*80*236 |
| NR-TL0153-30-30K-BK-24D | NR-TL0153-30-30K-BK-24D | LED Track Light | Portable | Class II | IP20 | 40°C | AC220-240V | Hz | COB | 30.0 | 74.0 | 2220.0 | 3000K | 24° | 90 | 0.9 | 0.9 | Black | Aluminum + PC | Non-Adjustable Light | N/A | 5 | Direct | 158*80*236 |
| NR-TL0154-30-40K-BK-24D | NR-TL0154-30-40K-BK-24D | LED Track Light | Portable | Class I | IP20 | 40°C | AC220-240V | Hz | COB | 30.0 | 100.0 | 3000.0 | 4000K | 24° | 90 | 0.9 | 0.9 | Black | Non-Adjustable Light | N/A | 5 | Direct | 234*80*255 | |
| NR-TL0155-30-19K-BK-24D | NR-TL0155-30-18K-BK-24D | LED Track Light | Portable | Class I | IP20 | 40°C | AC220-240V | Hz | COB | 30.0 | 50.0 | 1500.0 | 1800K | 24° | 90 | 0.9 | 0.9 | Black | Non-Adjustable Light | N/A | 5 | Direct | 200*80*223 | |
| NR-TL0155-30-24K-BK-24D | NR-TL0155-30-24K-BK-24D | LED Track Light | Portable | Class I | IP20 | 40°C | AC220-240V | Hz | COB | 30.0 | 74.0 | 2220.0 | 2400K | 24° | 90 | 0.9 | 0.9 | Black | Non-Adjustable Light | N/A | 5 | Direct | 200*80*223 | |
| NR-TL0155-30-30K-BK-24D | NR-TL0155-30-30K-BK-24D | LED Track Light | Portable | Class I | IP20 | 40°C | AC220-240V | Hz | COB | 30.0 | 90.0 | 2700.0 | 3000K | 24° | 90 | 0.9 | 0.9 | Black | Non-Adjustable Light | N/A | 5 | Direct | 200*80*223 | |
| NR-TL0155-30-70K-BK-24D | NR-TL0155-30-65K-BK-24D | LED Track Light | Portable | Class I | IP20 | 40°C | AC220-240V | Hz | COB | 30.0 | 80.0 | 2400.0 | 6500K | 24° | 90 | 0.9 | 0.9 | Black | Non-Adjustable Light | N/A | 5 | Direct | 200*80*223 |
