NR-UL103-F/Y
POWER (WATT)
1.0
IP RATING
IP67
CCT
3000K
BEAM ANGLE
36°
Ra
80
Technical Specifications Basic Parameters
Model No
NR-UL103-F/NR-UL103-Y
Category
LED Outdoor Buried Lamp
Installation Methods
Recessed
Classes of Electrical Protection
Class III
IP Rating
IP67
ta
50°C
Input Voltage
DC24V
Frequency
Type of Chips
SMD
Watt
1.0
lm/w
20.0
Useful Lumen
20.0
CCT
3000K
Beam Angle
36°
Ra
80
PF
1.0
DF
1.0
Body Color
Silver
Product Main Material
Aluminum
Dimming or not
Non-Adjustable Light
Cut hole (mm)
Φ19
Guarantee
3
Directionality
Direct
Product Size (mm)
25*25*56/Φ25*56
Energy efficiency QR included
Model Variants 4 beam options
| Item Code | New Model No | Category | Installation Methods | Classes of Electrical Protection | IP Rating | ta | Input Voltage | Frequency | Type of Chips | Watt | lm/w | Useful Lumen | CCT | Beam Angle | Ra | PF | DF | Body Color | Product Main Material | Dimming or not | Cut hole (mm) | Guarantee | Directionality | Product Size (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NR-UL103-F | NR-LUL0102-1-30K-SL-36D | LED Outdoor Buried Lamp | Recessed | Class III | IP67 | 50°C | DC24V | N/A | SMD | 1.0 | 20.0 | 20.0 | 3000K | 36° | 80 | 1.0 | 1.0 | Silver | Aluminum | Non-Adjustable Light | Φ19 | 3 | Direct | 25*25*56 |
| NR-UL103-Y | NR-LUL0101-1-30K-SL-36D | LED Outdoor Buried Lamp | Recessed | Class III | IP67 | 50°C | DC24V | N/A | SMD | 1.0 | 20.0 | 20.0 | 3000K | 36° | 80 | 1.0 | 1.0 | Silver | Aluminum | Non-Adjustable Light | Φ19 | 3 | Direct | Φ25*56 |
