NR-FL103S Series
POWER (WATT)
50.0/100.0/150.0/200.0
IP RATING
IP65
CCT
3000K
BEAM ANGLE
60°
Ra
80
Technical Specifications Basic Parameters
Model No
NR-FL103S Series
Category
LED Flood Light
Installation Methods
Surface Mounted
Classes of Electrical Protection
Class I
IP Rating
IP65
ta
50°C
Input Voltage
AC220-240V
Frequency
Hz
Type of Chips
SMD
Watt
50.0/100.0/150.0/200.0
lm/w
107.2/107.0/106.0/113.3/101.0
Useful Lumen
5360.0/5350.0/10600.0/17000/16995/20200.0
CCT
3000K
Beam Angle
60°
Ra
80
PF
0.9
DF
0.9
Body Color
White/Black
Product Main Material
PC
Dimming or not
Non-Adjustable Light
Cut hole (mm)
Guarantee
3
Directionality
Direct
Product Size (mm)
210*45*225/285*50*320/335*50*375/382*60*412
Energy efficiency QR included
Model Variants 4 beam options
| Item Code | New Model No | Category | Installation Methods | Classes of Electrical Protection | IP Rating | ta | Input Voltage | Frequency | Type of Chips | Watt | lm/w | Useful Lumen | CCT | Beam Angle | Ra | PF | DF | Body Color | Product Main Material | Dimming or not | Cut hole (mm) | Guarantee | Directionality | Product Size (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NR-FL103S-50-3000K | NR-FL0201-50-30K-WH-60D | LED Flood Light | Surface Mounted | Class I | IP65 | 50°C | AC220-240V | Hz | SMD | 50.0 | 107.2 | 5360.0 | 3000K | 60° | 80 | 0.9 | 0.9 | White | PC | Non-Adjustable Light | N/A | 3 | Direct | 210*45*225 |
| NR-FL103S-50-6500K | NR-FL0201-50-65K-WH-60D | LED Flood Light | Surface Mounted | Class I | IP65 | 50°C | AC220-240V | Hz | SMD | 50.0 | 107.2 | 5360.0 | 3000K | 60° | 80 | 0.9 | 0.9 | White | PC | Non-Adjustable Light | N/A | 3 | Direct | 210*45*225 |
| NR-FL103S-50-BK-3000K | NR-FL0201-50-30K-BK-60D | LED Flood Light | Surface Mounted | Class I | IP65 | 50°C | AC220-240V | Hz | SMD | 50.0 | 107.0 | 5350.0 | 3000K | 60° | 80 | 0.9 | 0.9 | Black | PC | Non-Adjustable Light | N/A | 3 | Direct | 210*45*225 |
| NR-FL103S-50-BK-6500K | NR-FL0201-50-65K-BK-60D | LED Flood Light | Surface Mounted | Class I | IP65 | 50°C | AC220-240V | Hz | SMD | 50.0 | 107.0 | 5350.0 | 3000K | 60° | 80 | 0.9 | 0.9 | Black | PC | Non-Adjustable Light | N/A | 3 | Direct | 210*45*225 |
| NR-FL103S-100-3000K | NR-FL0101-100-30K-WH-60D | LED Flood Light | Surface Mounted | Class I | IP65 | 50°C | AC220-240V | Hz | SMD | 100.0 | 106.0 | 10600.0 | 3000K | 60° | 80 | 0.9 | 0.9 | White | PC | Non-Adjustable Light | N/A | 3 | Direct | 285*50*320 |
| NR-FL103S-100-6500K | NR-FL0101-100-65K-WH-60D | LED Flood Light | Surface Mounted | Class I | IP65 | 50°C | AC220-240V | Hz | SMD | 100.0 | 106.0 | 10600.0 | 3000K | 60° | 80 | 0.9 | 0.9 | White | PC | Non-Adjustable Light | N/A | 3 | Direct | 285*50*320 |
| NR-FL103S-100-BK-3000K | NR-FL0101-100-30K-BK-60D | LED Flood Light | Surface Mounted | Class I | IP65 | 50°C | AC220-240V | Hz | SMD | 100.0 | 106.0 | 10600.0 | 3000K | 60° | 80 | 0.9 | 0.9 | Black | PC | Non-Adjustable Light | N/A | 3 | Direct | 285*50*320 |
| NR-FL103S-100-BK-6500K | NR-FL0101-100-65K-BK-60D | LED Flood Light | Surface Mounted | Class I | IP65 | 50°C | AC220-240V | Hz | SMD | 100.0 | 106.0 | 10600.0 | 3000K | 60° | 80 | 0.9 | 0.9 | Black | PC | Non-Adjustable Light | N/A | 3 | Direct | 285*50*320 |
| NR-FL103S-150-3000K | NR-FL101-150S WW | LED Flood Light | Surface Mounted | Class I | IP65 | 50°C | AC220-240V | Hz | SMD | 150.0 | 113.3 | 17000 | 3000K | 60° | 80 | 0.9 | 0.9 | White | PC | Non-Adjustable Light | N/A | 3 | Direct | 335*50*375 |
| NR-FL103S-150-6500K | NR-FL0101-150-65K-WH-60D | LED Flood Light | Surface Mounted | Class I | IP65 | 50°C | AC220-240V | Hz | SMD | 150.0 | 113.3 | 16995 | 3000K | 60° | 80 | 0.9 | 0.9 | White | PC | Non-Adjustable Light | N/A | 3 | Direct | 335*50*375 |
| NR-FL103S-150-BK-3000K | NR-FL0101-150-30K-BK-60D | LED Flood Light | Surface Mounted | Class I | IP65 | 50°C | AC220-240V | Hz | SMD | 150.0 | 113.3 | 16995 | 3000K | 60° | 80 | 0.9 | 0.9 | Black | PC | Non-Adjustable Light | N/A | 3 | Direct | 335*50*375 |
| NR-FL103S-150-BK-6500K | NR-FL0101-150-65K-BK-60D | LED Flood Light | Surface Mounted | Class I | IP65 | 50°C | AC220-240V | Hz | SMD | 150.0 | 113.3 | 16995 | 3000K | 60° | 80 | 0.9 | 0.9 | Black | PC | Non-Adjustable Light | N/A | 3 | Direct | 335*50*375 |
| NR-FL103S-200-3000K | NR-FL103-200 WW | LED Flood Light | Surface Mounted | Class I | IP65 | 50°C | AC220-240V | Hz | SMD | 200.0 | 101.0 | 20200.0 | 3000K | 60° | 80 | 0.9 | 0.9 | White | PC | Non-Adjustable Light | N/A | 3 | Direct | 382*60*412 |
| NR-FL103S-200-6500K | NR-FL103-200 | LED Flood Light | Surface Mounted | Class I | IP65 | 50°C | AC220-240V | Hz | SMD | 200.0 | 101.0 | 20200.0 | 3000K | 60° | 80 | 0.9 | 0.9 | White | PC | Non-Adjustable Light | N/A | 3 | Direct | 382*60*412 |
| NR-FL103S-200-BK-3000K | NR-FL0151-200-30K-BK-60D | LED Flood Light | Surface Mounted | Class I | IP65 | 50°C | AC220-240V | Hz | SMD | 200.0 | 101.0 | 20200.0 | 3000K | 60° | 80 | 0.9 | 0.9 | Black | PC | Non-Adjustable Light | N/A | 3 | Direct | 382*60*412 |
| NR-FL103S-200-BK-6500K | NR-FL0151-200-65K-BK-60D | LED Flood Light | Surface Mounted | Class I | IP65 | 50°C | AC220-240V | Hz | SMD | 200.0 | 101.0 | 20200.0 | 3000K | 60° | 80 | 0.9 | 0.9 | Black | PC | Non-Adjustable Light | N/A | 3 | Direct | 382*60*412 |
