NR-PL102 Series
POWER (WATT)
50.0
IP RATING
IP20
CCT
3000K/4000K/6500K
BEAM ANGLE
120°
Ra
80
Technical Specifications Basic Parameters
Model No
NR-PL102-50 Series
Category
LED Panel Light
Installation Methods
Recessed
Classes of Electrical Protection
Class II+III
IP Rating
IP20
ta
40°C
Input Voltage
AC220-240V
Frequency
Hz
Type of Chips
SMD
Watt
50.0
lm/w
103.0/107.2
Useful Lumen
5150.0/5360.0
CCT
3000K/4000K/6500K
Beam Angle
120°
Ra
80
PF
0.9
DF
0.9
Body Color
White
Product Main Material
Aluminum
Dimming or not
Non-Adjustable Light
Cut hole (mm)
590*590
Guarantee
3
Directionality
Indirect
Product Size (mm)
596*596*31
Column 25
Energy efficiency QR included
Model Variants 4 beam options
| Item Code | Category | Installation Methods | Classes of Electrical Protection | IP Rating | ta | Input Voltage | Frequency | Type of Chips | Watt | lm/w | Useful Lumen | CCT | Beam Angle | Ra | PF | DF | Body Color | Product Main Material | Dimming or not | Cut hole (mm) | Guarantee | Directionality | Product Size (mm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NR-PL102-50-3000K | LED Panel Light | Recessed | Class II+III | IP20 | 40°C | AC220-240V | Hz | SMD | 50.0 | 103.0 | 5150.0 | 3000K | 120° | 80 | 0.9 | 0.9 | White | Aluminum | Non-Adjustable Light | 590*590 | 3 | Indirect | 596*596*31 | |
| NR-PL102-50-4000K | LED Panel Light | Recessed | Class II+III | IP20 | 40°C | AC220-240V | Hz | SMD | 50.0 | 107.2 | 5360.0 | 4000K | 120° | 80 | 0.9 | 0.9 | White | Aluminum | Non-Adjustable Light | 590*590 | 3 | Indirect | 596*596*31 | |
| NR-PL102-50-6500K | LED Panel Light | Recessed | Class II+III | IP20 | 40°C | AC220-240V | Hz | SMD | 50.0 | 103.0 | 5150.0 | 6500K | 120° | 80 | 0.9 | 0.9 | White | Aluminum | Non-Adjustable Light | 590*590 | 3 | Indirect | 596*596*31 |
