NR-SPL0102-18 Series
POWER (WATT)
18.0
IP RATING
IP20
CCT
3000K/6500K
BEAM ANGLE
120°
Ra
80
Technical Specifications Basic Parameters
Model No
NR-SPL0102-18 Series
Category
LED Panel Light
Installation Methods
Surface Mounted
Classes of Electrical Protection
Class II
IP Rating
IP20
ta
40°C
Input Voltage
AC220-240V
Frequency
Hz
Type of Chips
SMD
Watt
18.0
lm/w
80
Useful Lumen
1440
CCT
3000K/6500K
Beam Angle
120°
Ra
80
PF
0.5
DF
0.7
Body Color
White
Product Main Material
Engineering plastics
Dimming or not
Non-Adjustable Light
Cut hole (mm)
Guarantee
5
Directionality
Indirect
Product Size (mm)
190*190*35
Energy efficiency QR included
Model Variants 4 beam options
| New Model No | Category | Installation Methods | Classes of Electrical Protection | IP Rating | ta | Input Voltage | Frequency | Type of Chips | Watt | lm/w | Useful Lumen | CCT | Beam Angle | Ra | PF | DF | Body Color | Product Main Material | Dimming or not | Cut hole (mm) | Guarantee | Directionality | Product Size (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NR-SPL0102-18-30K-WH-120D | LED Panel Light | Surface Mounted | Class II | IP20 | 40°C | AC220-240V | Hz | SMD | 18.0 | 80 | 1440 | 3000K | 120° | 80 | 0.5 | 0.7 | White | Engineering plastics | Non-Adjustable Light | N/A | 5 | Indirect | 190*190*35 |
| NR-SPL0102-18-65K-WH-120D | LED Panel Light | Surface Mounted | Class II | IP20 | 40°C | AC220-240V | Hz | SMD | 18.0 | 80 | 1440 | 6500K | 120° | 80 | 0.5 | 0.7 | White | Engineering plastics | Non-Adjustable Light | N/A | 5 | Indirect | 190*190*35 |
