NR-DL113 Series
POWER (WATT)
6.0
IP RATING
IP20
CCT
3000K
BEAM ANGLE
45°
Ra
90
Technical Specifications Basic Parameters
Model No
NR-DL113 Series
Category
LED Downlight
Installation Methods
Recessed
Classes of Electrical Protection
Class II+III
IP Rating
IP20
ta
40°C
Input Voltage
AC220-240V
Frequency
Hz
Type of Chips
COB
Watt
6.0
lm/w
71.0
Useful Lumen
426.0
CCT
3000K
Beam Angle
45°
Ra
90
PF
0.5
DF
0.7
Body Color
Black/White
Product Main Material
Aluminum
Dimming or not
Non-Adjustable Light
Cut hole (mm)
Guarantee
3
Directionality
Direct
Product Size (mm)
Φ50*101/Φ50*201/Φ50*301
Energy efficiency QR included
Model Variants 4 beam options
| Item Code | Category | Installation Methods | Classes of Electrical Protection | IP Rating | ta | Input Voltage | Frequency | Type of Chips | Watt | lm/w | Useful Lumen | CCT | Beam Angle | Ra | PF | DF | Body Color | Product Main Material | Dimming or not | Cut hole (mm) | Guarantee | Directionality | Product Size (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NR-DL113-6-10-BK-3000K | LED Downlight | Recessed | Class II+III | IP20 | 40°C | AC220-240V | Hz | COB | 6.0 | 71.0 | 426.0 | 3000K | 45° | 90 | 0.5 | 0.7 | Black | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | Φ50*101 |
| NR-DL113-6-10-W-3000K | LED Downlight | Recessed | Class II+III | IP20 | 40°C | AC220-240V | Hz | COB | 6.0 | 71.0 | 426.0 | 3000K | 45° | 90 | 0.5 | 0.7 | White | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | Φ50*101 |
| NR-DL113-6-20-BK-3000K | LED Downlight | Recessed | Class II+III | IP20 | 40°C | AC220-240V | Hz | COB | 6.0 | 71.0 | 426.0 | 3000K | 45° | 90 | 0.5 | 0.7 | Black | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | Φ50*201 |
| NR-DL113-6-20-W-3000K | LED Downlight | Recessed | Class II+III | IP20 | 40°C | AC220-240V | Hz | COB | 6.0 | 71.0 | 426.0 | 3000K | 45° | 90 | 0.5 | 0.7 | White | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | Φ50*201 |
| NR-DL113-6-30-BK-3000K | LED Downlight | Recessed | Class II+III | IP20 | 40°C | AC220-240V | Hz | COB | 6.0 | 71.0 | 426.0 | 3000K | 45° | 90 | 0.5 | 0.7 | Black | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | Φ50*301 |
| NR-DL113-6-30-W-3000K | LED Downlight | Recessed | Class II+III | IP20 | 40°C | AC220-240V | Hz | COB | 6.0 | 71.0 | 426.0 | 3000K | 45° | 90 | 0.5 | 0.7 | White | Aluminum | Non-Adjustable Light | N/A | 3 | Direct | Φ50*301 |
