NRP-ORDL Series
POWER (WATT)
10.0/15.0/30.0/60.0/7.0/80.0
IP RATING
IP65
CCT
3000K/4000K/6500K
BEAM ANGLE
45°/60°
Ra
90
Technical Specifications Basic Parameters
Model No
NRP-ORDL0101 Series
Category
LED Downlight
Installation Methods
Recessed
Classes of Electrical Protection
Class II
IP Rating
IP65
ta
45°C/50°C
Input Voltage
AC220-240V
Frequency
Hz
Input Current
Cap Type
Lamp Type
Type of Chips
COB/SMD
Watt
10.0/15.0/30.0/60.0/7.0/80.0
lm/w
70.0/74.0/78.0/80.0/93.0/100.0/75.0/73.0/65.0
Useful Lumen
700.0/740.0/780.0/1200.0/1110.0/2790.0/3000.0/4500.0/4380.0/455.0/6000.0
CCT
3000K/4000K/6500K
Beam Angle
45°/60°
SDCM
<6
Ra
90
PF
0.5/0.9
DF
0.7/0.9
Body Color
Black/White
Product Main Material
Aluminum
Dimming or not
Non-Adjustable Light
Cut hole (mm)
Φ75/Φ100/Φ150/Φ205/Φ50
Guarantee
5
Directionality
Direct
Product Size (mm)
Φ87*73/Φ108*83/Φ162*112/Φ230*125/Φ55*51.5
Energy efficiency QR included
Model Variants 4 beam options
| New Model No | Category | Installation Methods | Classes of Electrical Protection | IP Rating | ta | Input Voltage | Frequency | Input Current | Cap Type | Lamp Type | Type of Chips | Watt | lm/w | Useful Lumen | CCT | Beam Angle | SDCM | Ra | PF | DF | Body Color | Product Main Material | Dimming or not | Cut hole (mm) | Guarantee | Directionality | Product Size (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NRP-ORDL0102-10-30K-BK-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 10.0 | 70.0 | 700.0 | 3000K | 45° | <6 | 90 | 0.5 | 0.7 | Black | Aluminum | Non-Adjustable Light | Φ75 | 5 | Direct | Φ87*73 | |
| NRP-ORDL0101-10-40K-BK-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 10.0 | 74.0 | 740.0 | 4000K | 45° | <6 | 90 | 0.5 | 0.7 | Black | Aluminum | Non-Adjustable Light | Φ75 | 5 | Direct | Φ87*73 | |
| NRP-ORDL0101-10-65K-BK-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 10.0 | 78.0 | 780.0 | 6500K | 45° | <6 | 90 | 0.5 | 0.7 | Black | Aluminum | Non-Adjustable Light | Φ75 | 5 | Direct | Φ87*73 | |
| NRP-ORDL0102-10-30K-WH-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 10.0 | 70.0 | 700.0 | 3000K | 45° | <6 | 90 | 0.5 | 0.7 | White | Aluminum | Non-Adjustable Light | Φ75 | 5 | Direct | Φ87*73 | |
| NRP-ORDL0101-10-40K-WH-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 10.0 | 74.0 | 740.0 | 4000K | 45° | <6 | 90 | 0.5 | 0.7 | White | Aluminum | Non-Adjustable Light | Φ75 | 5 | Direct | Φ87*73 | |
| NRP-ORDL0101-10-65K-WH-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 10.0 | 78.0 | 780.0 | 6500K | 45° | <6 | 90 | 0.5 | 0.7 | White | Aluminum | Non-Adjustable Light | Φ75 | 5 | Direct | Φ87*73 | |
| NRP-ORDL0101-15-30K-BK-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 15.0 | 80.0 | 1200.0 | 3000K | 45° | <6 | 90 | 0.5 | 0.7 | Black | Aluminum | Non-Adjustable Light | Φ100 | 5 | Direct | Φ108*83 | |
| NRP-ORDL0101-15-40K-BK-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 15.0 | 80.0 | 1200.0 | 4000K | 45° | <6 | 90 | 0.5 | 0.7 | Black | Aluminum | Non-Adjustable Light | Φ100 | 5 | Direct | Φ108*83 | |
| NRP-ORDL0101-15-65K-BK-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 15.0 | 80.0 | 1200.0 | 6500K | 45° | <6 | 90 | 0.5 | 0.7 | Black | Aluminum | Non-Adjustable Light | Φ100 | 5 | Direct | Φ108*83 | |
| NRP-ORDL0101-15-30K-WH-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 15.0 | 74.0 | 1110.0 | 3000K | 45° | <6 | 90 | 0.5 | 0.7 | White | Aluminum | Non-Adjustable Light | Φ100 | 5 | Direct | Φ108*83 | |
| NRP-ORDL0101-15-40K-WH-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 15.0 | 74.0 | 1110.0 | 4000K | 45° | <6 | 90 | 0.5 | 0.7 | White | Aluminum | Non-Adjustable Light | Φ100 | 5 | Direct | Φ108*83 | |
| NRP-ORDL0101-15-65K-WH-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 15.0 | 74.0 | 1110.0 | 6500K | 45° | <6 | 90 | 0.5 | 0.7 | White | Aluminum | Non-Adjustable Light | Φ100 | 5 | Direct | Φ108*83 | |
| NRP-ORDL0101-30-30K-BK-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 30.0 | 93.0 | 2790.0 | 3000K | 45° | <6 | 90 | 0.9 | 0.9 | Black | Aluminum | Non-Adjustable Light | Φ150 | 5 | Direct | Φ162*112 | |
| NRP-ORDL0101-30-40K-BK-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 30.0 | 100.0 | 3000.0 | 4000K | 45° | <6 | 90 | 0.9 | 0.9 | Black | Aluminum | Non-Adjustable Light | Φ150 | 5 | Direct | Φ162*112 | |
| NRP-ORDL0101-30-65K-BK-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 30.0 | 93.0 | 2790.0 | 6500K | 45° | <6 | 90 | 0.9 | 0.9 | Black | Aluminum | Non-Adjustable Light | Φ150 | 5 | Direct | Φ162*112 | |
| NRP-ORDL0101-30-30K-WH-45D | LED Downlight | Recessed | Class II | IP65 | 50°C | AC220-240V | Hz | N/A | N/A | COB | 30.0 | 93.0 | 2790.0 | 3000K | 45° | <6 | 90 | 0.9 | 0.9 | White | Aluminum | Non-Adjustable Light | Φ150 | 5 | Direct | Φ162*112 | |
| NRP-ORDL0101-30-40K-WH-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 30.0 | 100.0 | 3000.0 | 4000K | 45° | <6 | 90 | 0.9 | 0.9 | White | Aluminum | Non-Adjustable Light | Φ150 | 5 | Direct | Φ162*112 | |
| NRP-ORDL0101-30-65K-WH-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 30.0 | 93.0 | 2790.0 | 6500K | 45° | <6 | 90 | 0.9 | 0.9 | White | Aluminum | Non-Adjustable Light | Φ150 | 5 | Direct | Φ162*112 | |
| NRP-ORDL0101-60-30K-BK-60D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | SMD | 60.0 | 75.0 | 4500.0 | 3000K | 60° | <6 | 90 | 0.9 | 0.9 | Black | Aluminum | Non-Adjustable Light | Φ205 | 5 | Direct | Φ230*125 | |
| NRP-ORDL0101-60-40K-BK-60D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | SMD | 60.0 | 75.0 | 4500.0 | 4000K | 60° | <6 | 90 | 0.9 | 0.9 | Black | Aluminum | Non-Adjustable Light | Φ205 | 5 | Direct | Φ230*125 | |
| NRP-ORDL0101-60-65K-BK-60D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | SMD | 60.0 | 75.0 | 4500.0 | 6500K | 60° | <6 | 90 | 0.9 | 0.9 | Black | Aluminum | Non-Adjustable Light | Φ205 | 5 | Direct | Φ230*125 | |
| NRP-ORDL0101-60-30K-WH-60D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | SMD | 60.0 | 73.0 | 4380.0 | 3000K | 60° | <6 | 90 | 0.9 | 0.9 | White | Aluminum | Non-Adjustable Light | Φ205 | 5 | Direct | Φ230*125 | |
| NRP-ORDL0101-60-40K-WH-60D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | SMD | 60.0 | 75.0 | 4500.0 | 4000K | 60° | <6 | 90 | 0.9 | 0.9 | White | Aluminum | Non-Adjustable Light | Φ205 | 5 | Direct | Φ230*125 | |
| NRP-ORDL0101-60-65K-WH-60D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | SMD | 60.0 | 75.0 | 4500.0 | 6500K | 60° | <6 | 90 | 0.9 | 0.9 | White | Aluminum | Non-Adjustable Light | Φ205 | 5 | Direct | Φ230*125 | |
| NRP-ORDL0101-7-30K-WH-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 7.0 | 65.0 | 455.0 | 3000K | 45° | <6 | 90 | 0.5 | 0.7 | White | Aluminum | Non-Adjustable Light | Φ50 | 5 | Direct | Φ55*51.5 | |
| NRP-ORDL0101-7-40K-WH-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 7.0 | 65.0 | 455.0 | 4000K | 45° | <6 | 90 | 0.5 | 0.7 | White | Aluminum | Non-Adjustable Light | Φ50 | 5 | Direct | Φ55*51.5 | |
| NRP-ORDL0101-7-65K-WH-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 7.0 | 65.0 | 455.0 | 6500K | 45° | <6 | 90 | 0.5 | 0.7 | White | Aluminum | Non-Adjustable Light | Φ50 | 5 | Direct | Φ55*51.5 | |
| NRP-ORDL0101-7-30K-BK-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 7.0 | 65.0 | 455.0 | 3000K | 45° | <6 | 90 | 0.5 | 0.7 | White | Aluminum | Non-Adjustable Light | Φ50 | 5 | Direct | Φ55*51.5 | |
| NRP-ORDL0101-7-40K-BK-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 7.0 | 65.0 | 455.0 | 4000K | 45° | <6 | 90 | 0.5 | 0.7 | White | Aluminum | Non-Adjustable Light | Φ50 | 5 | Direct | Φ55*51.5 | |
| NRP-ORDL0101-7-65K-BK-45D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | COB | 7.0 | 65.0 | 455.0 | 6500K | 45° | <6 | 90 | 0.5 | 0.7 | White | Aluminum | Non-Adjustable Light | Φ50 | 5 | Direct | Φ55*51.5 | |
| NRP-ORDL0101-80-30K-BK-60D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | SMD | 80.0 | 75.0 | 6000.0 | 3000K | 60° | <6 | 90 | 0.9 | 0.9 | Black | Aluminum | Non-Adjustable Light | Φ205 | 5 | Direct | Φ230*125 | |
| NRP-ORDL0101-80-40K-BK-60D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | SMD | 80.0 | 75.0 | 6000.0 | 4000K | 60° | <6 | 90 | 0.9 | 0.9 | Black | Aluminum | Non-Adjustable Light | Φ205 | 5 | Direct | Φ230*125 | |
| NRP-ORDL0101-80-65K-BK-60D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | SMD | 80.0 | 75.0 | 6000.0 | 6500K | 60° | <6 | 90 | 0.9 | 0.9 | Black | Aluminum | Non-Adjustable Light | Φ205 | 5 | Direct | Φ230*125 | |
| NRP-ORDL0101-80-30K-WH-60D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | SMD | 80.0 | 75.0 | 6000.0 | 3000K | 60° | <6 | 90 | 0.9 | 0.9 | White | Aluminum | Non-Adjustable Light | Φ205 | 5 | Direct | Φ230*125 | |
| NRP-ORDL0101-80-40K-WH-60D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | SMD | 80.0 | 75.0 | 6000.0 | 4000K | 60° | <6 | 90 | 0.9 | 0.9 | White | Aluminum | Non-Adjustable Light | Φ205 | 5 | Direct | Φ230*125 | |
| NRP-ORDL0101-80-65K-WH-60D | LED Downlight | Recessed | Class II | IP65 | 45°C | AC220-240V | Hz | N/A | N/A | SMD | 80.0 | 75.0 | 6000.0 | 6500K | 60° | <6 | 90 | 0.9 | 0.9 | White | Aluminum | Non-Adjustable Light | Φ205 | 5 | Direct | Φ230*125 |
